Route Details




FL.NO: CDA606

From : TNCM Philipsburg
To   : MUCM Camaguay
Alt  : MUHG Holguin
(HDG 117°M 95NM FROM MUCM)

ETD  10:30Z    ALT  :35,000
ETA  12:40Z    SPEED:M. 77
ETE  02:10     A/C  :BAC1-11
FUEL 3000 KG   SET  :6808 KG

Flightplan

Procedures

ISEC Nav Points
See Charts Department for SIDs, STARs, IAP, ENROUTE



JUICE	N18.07.86 W063.40.00
LARPP	N18.12.33 W064.06.74
YAKKY	N18.17.69 W064.39.00
FORTN	N18.24.45 W065.30.37
KATOK	N18.49.85 W066.00.00
BETUM	N18.59.57 W069.00.90
KODIX	N19.08.18 W070.08.57
POBIN	N19.23.83 W070.57.25
MEDON	N19.46.10 W073.00.80
BOBIN	N19.54.71 W074.45.37
BAIRE	N20.54.05 W077.28.13

Airfield Data


Philipsburg ELEV 9ft

09/27 7053ft
VOR PJM 113.00


Camaguay ELEV 406ft

07 ILS/GS 110.30 ICM 072°
25 NO ILS (Both 9843ft)
VOR UCM 114.10
NDB UCM 370.00


Holguin ELEV 347ft

05 ILS/GS 111.30 IHG 052°
23 NO ILS (Both 10302ft)
VOR UHG 116.80
