Route Details




FL.NO: CDA607

From : MUCM Camaguay
To   : TNCM Philipsburg
Alt  : TKPK Bradshaw INTL
(HDG 165°M 50NM FROM TNCM)

ETD  13:30Z    ALT  :35,000
ETA  15:40Z    SPEED:M. 77
ETE  02:10     A/C  :BAC1-11
FUEL 3000 KG   SET  :6808 KG

Flightplan

Procedures

ISEC Nav Points
See Charts Department for SIDs, STARs, IAP, ENROUTE



BYGON	N20.32.01 W073.48.95
BODLO	N20.24.39 W073.00.49
BETIR	N19.20.59 W068.36.26
ROBLE	N18.57.27 W067.00.84
NUBON	N18.09.87 W064.25.00
GOUDA	N17.56.04 W063.40.00
UMANA	N17.55.94 W063.16.59

Airfield Data


Camaguay ELEV 406ft

07 ILS/GS 110.30 ICM 072°
25 NO ILS (Both 9843ft)
VOR UCM 114.10
NDB UCM 370.00


Philipsburg ELEV 9ft

09/27 7053ft
VOR PJM 113.00


Bradshaw INTL ELEV 167ft

07/25 8002ft
VOR SKB 112.00
NDB SKB 325.00
