Route Details




FL.NO: CDA610 (Leg 1)

From : TNCM Philipsburg
To   : TJSJ San Juan
Alt  : TIST Saint Thomas
(HDG 107°M 60NM FROM TJSJ)

ETD  14:40Z    ALT  :FL180
ETA  15:15Z    SPEED:300kts
ETE  00:35     A/C  :BAC1-11
FUEL 3000 KG   SET  :6808 KG

Use above fuel for both legs

Flightplan



FL.NO: CDA610 (Leg 2)

From : TJSJ San Juan
To   : MDSD Santo Domingo
Alt  : MDPC Punta Cana INTL
(HDG 093°M 75NM FROM MDSD)

ETD  15:50Z    ALT  :FL230
ETA  16:40Z    SPEED:M.77
ETE  00:50     A/C  :BAC1-11

Flightplan

Procedures

ISEC Nav Points
See Charts Department for SIDs, STARs, IAP, ENROUTE



EBGAN	N18.07.37 W063.13.93
SLUGO	N18.23.37 W063.40.00
FORTN	N18.24.45 W065.30.37

BOCCA	N18.28.56 W066.36.14
PEBLO	N18.29.19 W066.50.73
DESGA	N18.38.04 W068.33.71
BIBOK	N18.43.72 W069.19.43

Airfield Data


Philipsburg ELEV 9ft

09/27 7053ft
VOR PJM 113.00


San Juan ELEV 9ft

08 ILS/GS 110.30 ISJU 078°
26 NO ILS (Both 1002ft)

10 ILS/GS 109.700 ICLA 101°
28 NO ILS (Both 8016ft)
VORTAC SJU 114.00


Santo Domingo ELEV 55ft

17 ILS/GS/DME 108.90 ICDO 169°
35 NO ILS (Both 11000ft)
VOR CDO 114.70
NDB HIV 400.00


Saint Thomas ELEV 22ft

10 ILS/GS/DME 110.10 ITMN 100°
28 NO ILS (Both 7000ft)


Punta Cana INTL ELEV 39ft

09/27 8980ft
VOR PNA 112.70
NDB PCA 425.00
