Route Details




FL.NO: CDA612 (Leg 1)

From : TNCM Philipsburg
To   : MYNN Nassau INTL
Alt  : MYEM Governors Harbour
(HDG 081°M 63NM FROM MYNN)

ETD  13:30Z    ALT  :FL350
ETA  15:45Z    SPEED:M.77
ETE  02:15     A/C  :BAC1-11
FUEL 3500 KG   SET  :6808 KG

Use above fuel for both legs

Flightplan



FL.NO: CDA612 (Leg 2)

From : MYNN Nassau INTL
To   : KMIA Miami INTL
Alt  : KPBI Palm Beach INTL
(HDG 015°M 55NM FROM KMIA)

ETD  16:10Z    ALT  :FL180
ETA  16:40Z    SPEED:290kts
ETE  00:30     A/C  :BAC1-11

Flightplan

Procedures

ISEC Nav Points
See Charts Department for SIDs, STARs, IAP, ENROUTE



JUICE	N18.07.86 W063.40.00
LARPP	N18.12.33 W064.06.74
SAALR	N19.06.79 W066.20.17
UTAHS	N19.41.43 W067.17.21
OTTIS	N20.47.31 W069.17.94
RAHAM	N22.22.76 W072.11.26
INDEE	N23.08.39 W074.23.37
VICTS	N24.42.47 W076.57.46

PRUNE	N25.13.08 W077.57.59
RAJAY	N25.17.99 W078.10.88
LUVLY	N25.39.74 W080.08.33

Airfield Data


Philipsburg ELEV 9ft

09/27 7053ft
VOR PJM 113.00



Nassau INTL elev 9ft

14/32 11000FT
VOR ZQA 112.70
NDB ZQA 251.00



Governors Harbour ELEV 22ft

15/33 8450ft
VOR ZGV 112.50
NDB ELJ 224.00


Miami INTL ELEV 9ft

09L ILS/GS/DME 110.30 IMFA 090°
27R ILS/GS 190.10 IVIN 270°
(Both 10502ft)

09R ILS/GS 110.90 IBUL 090°
27L ILS/GS 109.50 IMIA 270°
(Both 13000ft)

12 ILS/GS/DME 108.90 IGEM 122°
30 ILS/GS/DME 111.70 IDCX 302°
(Both 9355ft)


Palm Beach INTL ELEV 16ft

09L ILS/GS 111.90 IPBI 097°
27R NO ILS (Both 7989ft)

13/31 6930ft
VOR PBI 115.70
