Route Details




FL.NO: CDA614

From : TNCM Philipsburg
To   : MUHA Havana
Alt  : MUVR Veradero
(HDG 089°M 54NM FROM MUHA)

ETD  16:30Z    ALT  :FL350
ETA  19:20Z    SPEED:M.77
ETE  02:50     A/C  :BAC1-11
FUEL 3000 KG   SET  :6808 KG

Flightplan

Procedures

ISEC Nav Points
See Charts Department for SIDs, STARs, IAP, ENROUTE



JUICE	N18.07.86 W063.40.00
LARPP	N18.12.33 W064.06.74
YAKKY	N18.17.69 W064.39.00
FORTN	N18.24.45 W065.30.37
BOCCA	N18.28.56 W066.36.14
PEBLO	N18.29.19 W066.50.73
AQABA	N18.35.75 W067.22.48
KATOK	N18.49.85 W068.00.00
PETRI	N19.16.13 W069.42.03
JOSES	N20.08.66 W073.13.09
PALOS	N22.33.37 W081.26.33

Airfield Data


Philipsburg ELEV 9ft

09/27 7053ft
VOR PJM 113.00


Havana ELEV 209ft

05 ILS/GS 110.50 IHA 055°
23 NO ILS (Both 13123ft)
VOR UHA 116.10
NDB UHA 348.00


Veradero ELEV 209ft

06 ILS/GS 111.30 IVR 058°
24 NO ILS (Both 11483ft)
VOR UVA 114.80
NDB VA  430.00
