Route Details

Route By Jonathan (165)
Flightplan By Jonathan & Dave (109)




FL.NO: CDAC690  Leg1

From : MKJS SANGSTER INTL
To   : KMIA MIAMI INTL
Alt  : KTPA TAMPA INTL
(HDG 321°M 178NM FROM KMIA)

ETD  21:30Z      ALT :FL310
ETA  22:50Z      MACH:0.77
ETE  01:19       A/C :DC8-73F
FUEL 30122KG     SET :45000KG

*Use set fuel for both legs*
CDAC DC8-73F N957R on the ramp MKJS Sangster Intl

Download cdacgps.zip Download cdacfsn4.zip Download cdacfsn3.zip



FL.NO: CDAC690  Leg2
From : KMIA MIAMI INTL
To   : MKJS SANGSTER INTL
Alt  : MUCU ANTONIO MACEO INTL
(HDG 056°M 148NM FROM MKJS)

ETD  23:50Z      ALT :FL320
ETA  01:10Z      MACH:0.78
ETE  01:19       A/C :DC8-73F
Lined up 27R for departure

Procedures

ISEC Nav Points

See Charts Department for SIDs, STARs, IAP, ENROUTE



URSUS	N24.00.00 W079.04.19
FOWEE	N24.56.22 W079.11.55
JUNUR	N25.23.27 W079.43.33

ELLEE	N24.52.84 W079.41.50
TANIA	N24.01.81 W079.31.65
PUTUL	N19.58.60 W078.17.63

Airfield Data


SANGSTER ELEV 3ft

07 VOR/DME MBJ 115.70 068°
25 VOR/DME MBJ 115.70 248°
(BOTH 8704ft)

NDB MBJ 248.0


MIAMI ELEV 9ft

09L ILS/GS/DME IMFA 110.30 090°
27R ILS/GS/DME IVIN 109.10 270°
(BOTH 10502ft)

09R ILS/GS/DME IBUL 110.90 090°
27L ILS/GS/DME IMIA 109.50 270°
(BOTH 13000ft)

12 ILS/GS/DME IGEM 108.90 122°
30 ILS/GS/DME IDCX 111.70 302°
(BOTH 9355ft)


TAMPA ELEV 26ft

18L ILS/GS ITPA 110.30 184°
36R ILS/BC ITPA 110.30 004°
(BOTH 8300ft)

18R ILS/GS/DME IJRT 108.50 184°
36L ILS/GS IAMP 108.90 004°
(BOTH 11002ft)


MACEO INTL ELEV 246ft

09 ILS/GS ICU 110.70 094°
27 NO ILS
(BOTH 13123ft)

VOR ICU 113.30
NDB UCU 339.0
