Route Details

Route By Roberto/Ade/Dave
Flightplan By Roberto/Dave/Mark

Mission Briefing by Mark:
Owing to a shortage of Blood Donors in the UK, our aircraft has been chartered to
collect some supplies from Spain. Bring them back to Manston for redistribution
around the NHS.



FL.NO: UKE669

From : LEMD MADRID
To   : EGMH MANSTON
Alt  : EGMC SOUTHEND
       (HDG 304°M 28NM from EGMH)

ETD  12:30Z      ALT :FL390
ETA  14:30Z     MACH :.82
ETE  02:00       A/C :CL601
FUEL 1590KG      SET :3900KG

Flightplann

Procedures

ISEC Nav Points

See Charts Department for SIDs, STARs, IAP, ENROUTE

BELEN	N43.54.81 W002.44.20
LAGOR	N46.30.00 W001.50.65
KOKOS	N48.54.42 W001.40.57
BARLU	N49.41.30 W001.18.70
FAWBO	N50.00.00 W001.19.18

Airfield Data


EGMH MANSTON ELEV 177ft

10 NO ILS
28 ILS/GS/DME IMSN 111.75 285°
(BOTH 8993ft)

EGMC SOUTHEND ELEV 88ft

06 NO ILS
24 ILS/GS/DME IND 111.35 243°
(BOTH 5266ft)
NDB SND 362.50


LEMD MADRID ELEV 1994ft

15 NO ILS
33 ILS/GS/DME MAA 109.90 328°
(BOTH 13751ft)
18 ILS/GS/DME MDZ 109.30 185°
36 ILS/GS/DME BJS 110.30 005°
(BOTH 12139ft)
VOR MAT 116.45
