Route Details

Route By Dave (109)
Flightplan By Dave (109)




FL.NO: UKD312 (Leg 1)

From : EGGP LIVERPOOL
To   : EGNS RONALDSWAY
Alt  : EGNH BLACKPOOL
(HDG 116°M 60NM from EGNS)

ETD  10:00Z    ALT  :12,000
ETA  10:25Z    SPEED:260KTS
ETE  00:25     A/C  :Bae ATP
FUEL 1168KG    SET  : 3100KG

Flightplan





FL.NO: UKD312 (Leg 2)

From : EGNS RONALDSWAY
To   : EGNT NEWCASTLE
Alt  : EGNV TEESSIDE
(HDG 171°M 34NM from EGNT)

ETD  10:45Z    ALT  :16,000
ETA  11:20Z    SPEED:260KTS
ETE  00:35     A/C  :Bae ATP
FUEL 1168KG    SET  : 3100KG

Flightplan

Procedures

ISEC Nav Points
See Charts Department for SIDs, STARs, IAP, ENROUTE

KELLY	N53.54.32 W004.21.85
SHAPP	N54.30.00 W002.37.63

Airfield Data


LIVERPOOL ELEV 78ft

09 LOC/DME LVR 111.75 092°
27 ILS/GS/DME ILQ 111.75 272°
(Both 7500ft)

RONALDSWAY ELEV 32ft

08 NO ILS (Both 5751ft)
26 ILS/GS/DME IRY 110.90 265°


NEWCASTLE ELEV 265ft

07 ILS/GS/DME INC 110.50 071°
25 ILS/GS/DME INWC 110.50 251°
(Both 7650ft)

BLACKPOOL ELEV 88ft

10 NO ILS
28 ILS/GS/DME IBPL 108.10 281°
(Both 6132ft)

TEESSIDE ELEV 114ft

05 ILS/GS/DME ITD 108.50 053°
23 ILS/GS/DME ITSE 108.50 233°
(Both 7873ft)
