Route Details

Route By Mark (178)
Flightplan By Dave (109)




FL.NO: UKD380 (Leg 1)

From : EGSS STANSTED
To   : EKCH COPENHAGEN
Alt  : ESSA STOCKHOLM
(HDG 033°M 295NM from EKCH)

ETD  20:00Z      ALT :35,000
ETA  21:25Z      MACH:0.79
ETE  01:25       A/C :B737-800
FUEL 8575KG      SET :15960KG

Load set fuel above to cover
the three legs of the flight.

Flightplan




FL.NO: UKD380 (Leg 2)

From : EKCH COPENHAGEN
To   : ESSA STOCKHOLM
Alt  : ENGM OSLO
(HDG 277°M 208NM from ESSA)

ETD  22:00Z      ALT :35,000
ETA  23:00Z      MACH:0.79
ETE  01:00       A/C :B737-800

Flightplan




FL.NO: UKD380 (Leg 3)

From : ESSA STOCKHOLM
To   : ENGM OSLO
Alt  : ENBR BERGEN
(HDG 275°M 175NM from ENGM)

ETD  23:40Z      ALT :31,000
ETA  00:30Z      MACH:0.77
ETE  00:50       A/C :B737-800

Flightplan

Procedures

ISEC Nav Points
See Charts Department for SIDs, STARs, IAP, ENROUTE

GABAD	N52.01.78 E002.03.02
REDFA	N52.06.88 E002.29.28
TULIP	N52.22.07 E003.51.43
ANDIK	N52.44.37 E005.16.23
GRONY	N56.06.33 E006.03.30
JUIST	N53.33.77 E006.55.20
TALSA	N55.06.42 E009.41.18
LUGAS	N55.19.78 E010.57.78
SIMEG	N55.15.00 E013.30.07

Airfield Data


STANSTED ELEV 347ft

05 ILS/GS/DME ISED 110.50 048°
25 ILS/GS/DME ISX 110.50 228°
(Both 10000ft)


COPENHAGEN ELEV 16ft

04L ILS/GS/DME CH 110.50 041°
22R ILS/GS/DME KLK 110.90 221°
(Both 11682ft)

04R ILS/GS/DME NE 109.30 041°
22L ILS/GS/DME OXS 109.50 221°
(Both 10829ft)

12 ILS/GS/DME KA 109.90 123°
30 ILS/GS/DME OY 108.90 303°
(Both 7650ft)


STOCKHOLM ELEV 121ft

01 ILS/GS SSA 109.90 009°
19 ILS/GS NSA 110.70 189°
(Both 10827ft)

08 ILS/GS WSA 109.55 074°
26 ILS/GS ESA 110.10 254°
(Both 8202ft)


OSLO ELEV 669ft

01L ILS/GS/DME GA 109.50 018°
19R ILS/GS/DME GM 111.70 198°
(Both 12300ft)

01R ILS/GS/DME ONE 111.95 018°
19L ILS/GS/DME GME 110.55 198°
(Both 11500ft)


BERGEN ELEV 164ft

17 ILS/GS/DME BR 109.90 170°
35 ILS/GS/DME BG 110.90 350°
(Both 10000ft)
