Route Details

Route By Mark (178)
Flightplan By Dave (109)




FL.NO: UKD420 (Leg 1)

From : EGJJ JERSEY
To   : EGJA ALDERNEY
Alt  : EGJJ JERSEY
(HDG 184°M 30NM from EGJA)

ETD  07:00Z    ALT  :5,000
ETA  07:25Z    SPEED:190KTS
ETE  00:25     A/C  :DHC6-300S
FUEL 333 KG   SET  :2171 KG

Use above fuel for both legs

Flightplan





FL.NO: UKD420 (Leg 2)

From : EGJA ALDERNEY
To   : EGTE EXETER
Alt  : EGHD PLYMOUTH
(HDG 241°M 32NM from EGTE)

ETD  07:55Z    ALT  :9,000
ETA  08:40Z    SPEED:190KTS
ETE  00:45     A/C  :DHC6-300S

Flightplan

Procedures

ISEC Nav Points
See Charts Department for SIDs, STARs, IAP, ENROUTE

RUPAS	N49.30.00 W002.00.00
AGANO	N49.39.93 W002.00.00
ANGLA	N49.42.23 W002.01.25
BRILL	N49.42.15 W002.23.38
LUMEK	N50.25.83 W003.13.57
DAWLY	N50.34.45 W003.27.83

Airfield Data


JERSEY ELEV 285ft

09 ILS/GS/DME IJJ 110.90 087°
27 ILS/GS/DME IDD 110.30 267°
(BOTH 5597ft)


ALDERNEY ELEV 291ft

08/26 2723ft
03/21 1630ft
14/32 2401ft

NDB ALD 383.0


EXETER ELEV 101 FT

08 ILS/GS/DME IET 109.90 082°
26 ILS/GS/DME IXR 109.90 262°
(BOTH 6833ft)


PLYMOUTH ELEV 472ft

13 ILS/GS/DME IPLM 109.50 129°
31 ILS/GS/DME IPLY 109.50 309°
(BOTH 3838ft)
