Route Details

Route By G.Summons (100)
Flightplan By Dave (109)



FL.NO: UKD506

From : EGNV TEESSIDE
To   : EGMC SOUTHEND
Alt  : EGMH KENT INTL
(HDG 124°M 28NM FROM EGMC)

ETD  07:30Z    ALT  :FL150
ETA  08:30Z    SPEED:240kts
ETE  01:00     A/C  :SF340
FUEL 605 KG    SET  :1200 KG

Flightplan

Procedures

ISEC Nav Points
See Charts Department for SIDs, STARs, IAP, ENROUTE



GASKO	N54.13.48 W001.57.35
CLIPY	N52.00.05 W001.05.15
BOMBO	N51.59.73 W000.23.78
BRAIN	N51.48.67 E000.39.10
MAYLA	N51.37.68 E000.43.20
SPEAR	N51.34.57 E000.42.02

Airfield Data


TEESSIDE ELEV 114ft

05 ILS/GS/DME ITD  108.50 053°
23 ILS/GS/DME ITSE 108.50 233°
(BOTH 7873ft)


SOUTHEND ELEV 88ft

06 NO ILS
24 ILS/GS/DME IND 111.35 243°
(BOTH 5266ft)

NDB SND 362.50



KENT INTL ELEV 177ft

10 NO ILS
28 ILS/GS/DME IMSN 111.75 285°
(BOTH 8993ft)
