Route Details

Route & Flightplan By Dave (109)




FL.NO: UKD532 (Leg 1)

From : LFAT LE TOUQUET
To   : LFAC CALAIS
Alt  : LFAT LE TOUQUET
(HDG 209°M 29NM FROM LFAC)


ETD  13:00Z    ALT  :FL60
ETA  13:20Z    SPEED:240kts
ETE  00:20     A/C  :DO328
FUEL 1060 KG   SET  :1700 KG

Use above fuel for both legs

Flightplan



FL.NO: UKD532 (Leg 2)

From : LFAC CALAIS
To   : EGMC SOUTHEND
Alt  : EGMH KENT INTL
(HDG 124°M 28NM FROM EGMC)

ETD  13:30Z    ALT  :FL120
ETA  14:00Z    SPEED:240kts
ETE  00:30     A/C  :DO328

Flightplan

Procedures

ISEC Nav Points
SIDS - Le Touquet
BNE 1Y RWY14 On 137 track to 600, turn LEFT, intercept BNE R219 inbound to BNE VOR.

BNE 1Z RWY32 On 317 track to 600, turn RIGHT, intercept BNE R271 inbound to BNE VOR.

SIDS - Calais
DVR 2G RWY24 Climb on 244 track to 500, turn RIGHT 283 track. Intercept DVR R-133 inbound to DVR VORDME.

DVR 2J RWY06 Climb on 064 track to 500, turn RIGHT 268 track. Intercept DVR R-133 inbound to DVR VORDME.

532a
TRACA	N50.51.10 E001.58.10

532b
FIR17	N51.01.97 E001.36.93
SPEAR	N51.34.57 E000.42.02

Airfield Data


LE TOUQUET ELEV 170ft

14 ILS/GS/DME LFTA 109.10 141°
32 NO ILS
(BOTH 7381ft)


CALAIS ELEV 6ft

06 NO ILS
23 ILS/GS/DME MK 110.50 248°
(BOTH 5036ft)


SOUTHEND ELEV 88ft

06 NO ILS
24 ILS/GS/DME IND 111.35 243°
(BOTH 5266ft)

NDB SND 362.50



KENT INTL ELEV 177ft

10 NO ILS
28 ILS/GS/DME IMSN 111.75 285°
(BOTH 8993ft)
