Route Details

Route By G.Summons (100)
Flightplan By Dave (109)



FL.NO: UKD537

From : EGMC SOUTHEND
To   : EGSY SHEFFIELD
Alt  : EGNJ HUMBERSIDE
(HDG 079°M 38NM FROM EGSY)

ETD  09:00Z    ALT  :FL150
ETA  10:00Z    SPEED:240kts
ETE  01:00     A/C  :SF340
FUEL 617 KG    SET  :1200 KG

Flightplan

Procedures

ISEC Nav Points
See Charts Department for SIDs, STARs, IAP, ENROUTE



POTON	N52.05.07 W000.25.63
LESTA	N52.44.45 W001.04.32
ROBIN	N52.57.80 W001.17.75
SPEAR	N51.34.57 E000.42.02

Airfield Data


SOUTHEND ELEV 88ft

06 NO ILS
24 ILS/GS/DME IND 111.35 243°
(BOTH 5266ft)

NDB SND 362.50


SHEFFIELD ELEV 229ft

10 NO ILS
28 ILS/GS/DME ISFH 110.35 280°
(BOTH 3973ft)

NDB SMF 333.00


HUMBERSIDE ELEV 160ft

03 NO ILS
21 ILS/GS/DME IHS 108.75 208°
(BOTH 7217ft)

NDB KIM 365.00
