Route Details Route By Gary (100)
Flightplan By Dave (109)


UKD810


From : EGKK LONDON GATWICK
To     : KEWR NEWARK INTL
Alt     : KPHL PHILADELPHIA INTL
(HDG 237°M 70NM from KEWR)

ETD 13:00Z       ALT :FL310
       13:00local SPD :M.84 / 314KIAS
ETA 19:40Z       A/C  :B747-400
       15:40local
ETE 06:31
RTE 067934 KG   SET :099375 KG
RTE 149781 LBS SET :219103 LBS
Revised 11/09/01 - New Route & Fuel figure
Flightplan
FLIGHTPLANS created using the latest ARINC cycle data in formats - FSNav4, FSNav3, FS2000, Squawkbox, ACS GPS, Radar Contact and Text
Procedures
See Charts Department for SIDs, STARs, IAP, ENROUTE

Airfield Data
EGKK LONDON GATWICK ELEV 193ft
08R ILS/GS/DME IGG 110.90 083°
26L ILS/GS/DME IWW 111.70 263°
(BOTH 10876ft)

KPHL PHILADELPHIA INTL ELEV 19ft
09L ILS/GS/DME IVII 108.95 087°
27R ILS/GS/DME IPDP 108.95 267°
(BOTH 9488ft)
09R ILS/GS/DME IPHL 109.30 087°
27L ILS/GS/DME IGLC 109.30 267°
(BOTH 10486ft)


KEWR NEWARK INTL ELEV 16ft
04L ILS/GS/DME IEWR 110.75 039°
22R ILS/GS/DME IJNN 110.75 219°
(BOTH 8201ft)
04R ILS/GS/DME IEZA 108.70 039°
22L ILS/GS/DME ILSQ 108.70 219°
(BOTH 9982ft)
