Route Details Route By Mark (178)
Flightplan By Dave (109)


UKD834


From : EGKK LONDON GATWICK
To     : SBGL GALEAO INTL
Alt     : SBGR SAO PAULO INTL
(HDG 276°M 99NM from SBGL)

ETD 09:00Z       ALT :FL390
       09:00local SPD :M.85 / 280KIAS
ETA 19:08Z       A/C  :B777-200ER
        17:08local
ETE 10:08
RTE 104542 KG   SET :138656 KG
RTE 230494 LBS SET :305709 LBS
Revised 31/10/01 - New Route & Fuel figure
Flightplan
FLIGHTPLANS created using the latest ARINC cycle data in formats - FSNav4, FSNav3, FS2000, Squawkbox, ACS GPS, Radar Contact and Text
Procedures
See Charts Department for SIDs, STARs, IAP, ENROUTE

Airfield Data
EGKK LONDON GATWICK ELEV 193ft
08R ILS/GS/DME IGG 110.90 083°
26L ILS/GS/DME IWW 111.70 263°
(BOTH 10876ft)

SBGL GALEAO INTL ELEV 29ft
10 ILS/GS          ITB 109.30 095°
28 ILS/GS/DME ILM 109.30 275°
(BOTH 13203ft)
15 ILS/GS/DME IGL 110.30 146°
33 ILS/BC/DME IGL 110.30 326°
(BOTH 10380ft)


SBGR SAO PAULO INTL ELEV 2457ft
09L ILS/GS IUC 110.70 092°
27R ILS/BC IUC 110.70 272°
(BOTH 12151ft)
09R ILS/GS IGR 111.50 092°
27L ILS/GS IBC 111.10 272°
(BOTH 9819ft)
