Route Details Route By Mark (178)
Flightplan By Dave (109)


UKD835


From : SBGL GALEAO INTL
To     : EGKK LONDON GATWICK
Alt     : EGSS LONDON STANSTED
(HDG 025°M 48NM from EGKK)

ETD 22:00Z       ALT :FL390
       20:00local SPD :M.85 / 280KIAS
ETA 08:11Z       A/C  :B777-200ER
        08:11local
ETE 10:11
RTE 104969 KG   SET :138656 KG
RTE 231435 LBS SET :305709 LBS
Revised 31/10/01 - New Route & Fuel figure
Flightplan
FLIGHTPLANS created using the latest ARINC cycle data in formats - FSNav4, FSNav3, FS2000, Squawkbox, ACS GPS, Radar Contact and Text
Procedures
See Charts Department for SIDs, STARs, IAP, ENROUTE

Airfield Data
SBGL GALEAO INTL ELEV 29ft
10 ILS/GS         ITB 109.30 095°
28 ILS/GS/DME ILM 109.30 275°
(BOTH 13203ft)
15 ILS/GS/DME IGL 110.30 146°
33 ILS/BC/DME IGL 110.30 326°
(BOTH 10380ft)

EGKK LONDON GATWICK ELEV 193ft
08R ILS/GS/DME IGG 110.90 083°
26L ILS/GS/DME IWW 111.70 263°
(BOTH 10876ft)


EGSS LONDON STANSTED ELEV 347ft
05 ILS/GS/DME ISED 110.50 048°
23 ILS/GS/DME ISX   110.50 228°
(BOTH 9945ft)
